HASL Lead Free High Tg FR-4 Multilayer Surface Mount Pcb Assembly
Multilayer Electronics PCB Components Assmbly Introduction
The benefits of multilayer PCB boards Assembly compared with single layer or double layer PCB , Including :Higher Assembly Density
Smaller Size
Lighter Weight
Functionality Enhancement
A multi-layer circuit board can be called a multi-layer circuit board with more than two layers, such as four layers, six layers, eight layers, and so on. To increase circuit wiring, multi-layer PCB circuit boards use more single-sided or double-sided circuit boards. Use a double-sided board as the inner layer, two single-sided boards as the outer layer, or two double-sided printed circuit boards as the inner layer and two single-sided printed circuit boards as the outer layer.
Basic Information
| Model NO. | PCBA | Condition | New |
| MOQ | 1 PCs | Layer | 1-36 Layers |
| surface Finishing | HASL. Enig, OSP, Immersion
Au.AG,Sn | Min.Hole size | 0.05mm |
| Board Thickness | 0.3mm-3.5mm | Min.Line Spacing | 0.035mm |
| copper Thickness | 0.5oz-6oz(18 Um-770 um) | solder Mask | Green, White,Black.
Blue(Customized) |
| specialised | CE,LED.Medical, Industrial,
Control Board | service | PCB/PCBA/Circuit
Board/SMT/DIP |
| other Service | PCBA Layout and Design,
Engineering support | PCBA QA | X-ray,Aoi Test, Function
Test(100% Test) |
| Delivery | PCB,7-10 Days;PCBA,2-
3weeks | specification | CE,UL,SGS,IS09001,94v0 |
| Trademark | OEM PCB Assembly PCBA | Transport Package | Vacuum
Packing/Blister/Plastic
/Cartoon |
Multilayer Surface Mount Pcb Assembly Craftsmanship
Immersion gold ,Lead-free HASL,OSP, Immersion Au.AG,Sn ,FINGER GOLD ...
Our service
Electronic Manufacturing Service
Components Sourcing
Electronic Design
PCB Sourcing Service
PCB Layout Service
PCB Supplier & Quality Inspection Service
Delivery Time
| Product Type | Qty | Normal lead time | Quick-turn lead time |
| SMT+DIP | 1-50 | 1WD-2WD | 8H |
| SMT+DIP | 51-200 | 2WD-3WD | 1.5WD |
| SMT+DIP | 201-2000 | 3WD-4WD | 2WD |
| SMT+DIP | ≥2001 | 4WD-5WD | 3WD |
| PCBA(2-4Layer) | 1-50 | 2.5WD-3.5WD | 1WD |
| PCBA(2-4Layer) | 51-2000 | 5WD-6WD | 2.5WD |
| PCBA(2-4Layer) | ≥2001 | ≥7WD | 5WD |
| PCBA(6-10Layer) | 1-50 | 3WD-4WD | 2.5WD |
| PCBA(6-10Layer) | 51-2000 | 7WD-8WD | 6WD |
| PCBA(10-HDILayer) | 1-50 | 7WD-9WD | 5WD |
| PCBA(10-HDILayer) | 51-2000 | 9WD-11WD | 7WD |
Multilayer Electronics PCB Components Assembly Application Field
Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.
Workshop
Partners
Common packaging
PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box
FAQ
Q1.What are needed for quoation ?
PCB :Gerber File (Protel.Power PCB ,PADs File)
PCBA: Gerber File and BOM
Q2. What file formats do you accept for production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3.Are my files safe ?
Your files are held in complete safety and security ,we protect the intellectual property for our customers in the whole process .All documents from customer are never shared with any third parties .
Q4.What's your MOQ ?
No Moq ,We accept small orders as well as mass production
Q5.Shipping Cost ?
The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .
Q6.Can You provide fast rotating PCB ?
Yes , we can provide fast service 24 hours .
Q7.What are the services you can provide ?
One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
Q8.Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .
Q9.Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
Q10. Do you accept process materials supplied by clients?
A Yes, we can provide component source, and we also accept component from client
